cooling way: | |
---|---|
Color: | |
packing box: | |
standard: | |
ETD time: | |
Availability: | |
Quantity: | |
HW-50/4-200
BAILIAN
8414804090
reciprocating hydrogen piston compressor, as the name suggests, are devices that change the volume of hydrogen to complete compression and delivery. According to the principle, the hydrogen compressor can be divided into two types: volumetric type and speed type. Hydrogen compressors are available in diaphragm, reciprocating piston, rotary, screw, and turbine types.
Hydrogen is an important industrial raw material and has many uses in the industry. The common uses of hydrogen compressors are as follows:
reciprocating piston hydrogen compressor : filling hydrogen into high pressure bottle for storage, our hydrogen compressor filling pressure 150-200BARG
Decomposition of ammonia to produce hydrogen, pressurized for use in heat treatment of steel mill stainless steel
Photovoltaic power generation + hydrogen refueling station: electricity is produced by photovoltaic power generation, and then hydrogen is produced by water electrolysis. The hydrogen compressor in the general hydrogen refining station is pressurized to 400-450 barg, and is filled into a high-pressure hydrogen bottle to supply hydrogen energy vehicles. use.
safety piston reciprocating hydrogen compressor in chemical reactions, such as hydrogen compressors for polysilicon
Model | Working medium | suction pressure (Mpa,Psig) | Discharge pressure (Mpa,Psig) | Motor.KW | Flow rate Nm3/hr | Voltage | Cooling way |
HV-1/5 | Hydrogen | atmosphere | 0.5,72 | 0.75 | 1 | 220V/380V/415V/440V 50/60HZ | water cooling |
HV-15/0.5-9 | Hydrogen | 0.05,7 | 0.9,130 | 3 | 15 | 220V/380V/415V/440V 50/60HZ | water cooling |
HW-20/0.5-9 | Hydrogen | 0.05,7 | 0.9,130 | 4 | 20 | 220V/380V/415V/440V 50/60HZ | water cooling |
HV-17/3.4-21 | Hydrogen | 0.34,49 | 2.1,300 | 3 | 17 | 220V/380V/415V/440V 50/60HZ | water cooling |
HW-16/0.5-80 | Hydrogen | 0.05,7 | 8,1150 | 7.5 | 16 | 220V/380V/415V/440V 50/60HZ | water cooling |
GHV-2/2-150 | Hydrogen | 0.2,28 | 15,2160 | 1.5 | 2 | 220V/380V/415V/440V 50/60HZ | water cooling |
HW-10/4-200 | Hydrogen | 0.4,57 | 20,2875 | 4 | 10 | 220V/380V/415V/440V 50/60HZ | water cooling |
HD-40/200 | Hydrogen | atmosphere | 20,2875 | 22 | 40 | 220V/380V/415V/440V 50/60HZ | water cooling |
HW-50/4-200 | Hydrogen | 0.4,57 | 20,2875 | 18.5 | 50 | 220V/380V/415V/440V 50/60HZ | water cooling |
GHD-50/2-150 | Hydrogen | 0.2,28 | 15,2160 | 22 | 50 | 220V/380V/415V/440V 50/60HZ | water cooling |
HD-120/2-17 | Hydrogen | 0.2,28 | 1.7,244 | 22 | 120 | 220V/380V/415V/440V 50/60HZ | water cooling |
HD-100/0.5-25 | Hydrogen | 0.05,7 | 2.5,360 | 30 | 100 | 220V/380V/415V/440V 50/60HZ | water cooling |
HD-200/3 | Hydrogen | atmosphere | 0.3,43 | 30 | 200 | 220V/380V/415V/440V 50/60HZ | water cooling |
ZWH-200/0.8-12 | Hydrogen | 0.08,11.5 | 1.2,172 | 30 | 200 | 220V/380V/415V/440V 50/60HZ | water cooling |
1. The above parameters are for reference only, and subject to the final technical quotation
2. More displacement, higher filling pressure, please consult us
