ZWHY-500/0.9-60
What is the future development trend of hydrogen compressor?
Some hydrogen compressors are used to increase the hydrogen pressure for heat treatment of steel, and some use working conditions to use circulating hydrogen as a raw material for industrial reactions, and the hydrogen compressor provides continuous hydrogen pressure for the reactor. In the future, hydrogen compressors will be more used in hydrogen fuel cells to pressurize hydrogen to high pressure and inject it into hydrogen vehicles to obtain clean, green, and pollution-free energy.
Model | ZWHY-500/0.9-60 |
Medium | H2 |
Cooling mode | Water cooling |
Piston stroke mm | 180 |
Compression Stage | 4 |
Inlet pressure Mpa | 0.09 |
Discharge pressure Mpa | 6.0 |
Motor power kw | 110 |
Speed r/min | 420 |
Flow rate Nm3/h | 500 |
Cooling water pressure Mpa | ≥0.1 |
Lubricating oil pressure Mpa | ≥0.3 |
Dimension mm | 4000*2300*2850 |
Weight kg | 10000 |
