SF6-6/2-50
The advantage of the SF6 compressor is its compactness and simple construction.
Similar to electric motors, long-life lubricated and sealed roller bearings minimize friction in the crank mechanism. Therefore no oil is present in the entire compressor. Given enough attention, using the smallest manufacturing tolerances and high-tech materials, the SF6 compressor is not only economical but also very reliable. The SF6 compressor bearing of the connecting rod system enables the equipment to have a longer interval between replacement of the drive bearing during continuous operation, without the need for maintenance and adding lubricants.
When the SF6 compressor uses process gas in the production process, it may generate flue gas and leakage during the production process. This leads to the trend towards the use of closed-loop systems with gas in production processes and process technology.
The savings from the SF6 compressor can pay for the equipment investment in a short period of time.
Solemnly remind: the gas compressed by the compressor must be dry and particulate free gas!
TECHNICAL DATA | |||||
Medium | SF6 | Quantity | 1开 备 | ||
Inlet pressure MPa(G) | 0.2 | Inlet temperature ℃ | ≤ 40 | ||
Discharge pressure Mpa(G) | 5.0 | Discharge temperature(after cooling) ℃ | ≤ 50 | ||
Flow rate Nm3/h | 6 | Piston stroke mm | 63 | ||
Model | SF6-6/2-50 | Compression stages | 2 | ||
Structural style | Completely oil-free lubrication V-type | Cylinder quantity | 2 | ||
Shaft speed r/min | 300 ※ | Voltage V | 380 | ||
Cooling mode | Water cooling | Cooling water flow t/h | --- | ||
Shaft power kw | ≤2.0kw | Main motor speed r/min | 970 | ||
inlet and outlet interface mm | M33*1.5、M22*1.5 | Water Inlet and outlet interfaces mm | --- | ||
Motor | 3KW 380V 50Hz ※ | ||||
Dimensions mmXmmXmm | 1000X700X840 ※ | Weight T | 0.20 ※ | ||
Drive mode | Belt drive | ||||
Material of parts in contact with gas | cylinder | stainless steel | |||
Air valve | stainless steel | ||||
Pipeline, cooler | stainless steel | ||||
Scope of supply | Main engine, motor, skid mounted chassis, starting cabinet, intake filter, front primary meter and control components, safety valve, random documents, random spare parts, etc. (Note: The final technical agreement shall prevail). | ||||
Additional notes | Sealing method: magnetic fluid sealing. | ||||
Delivery time | 40 days after the contract is signed and the advance payment is received |
