ZW-240/3.5-64
Medium | N2 | Quantity | 1 | ||
Inlet pressure MPa（G） | 0.35 | Inlet temperature ℃ | 5～40 | ||
Discharge pressure Mpa（G） | 6.4 | Discharge temperature（after cooling） ℃ | ≤55 | ||
Flow rate Nm3/h | 240（whlie inlet pressure=0.35 MPa） | Piston stroke mm | 120 | ||
Model | ZW-240/3.5-64 | Compression stages | 3 | ||
Structural style | Reciprocating piston vertical sled mounted type | Cylinder quantity | 4 | ||
Shaft speed r/min | 485 ※ | Voltage V | 380V50Hz | ||
Cooling mode | Air cooling | Cooling water flow t/h | --- | ||
Shaft power kw | 36 | Main motor speed r/min | 485 ※ | ||
Motor | 45kw 380V50Hz---12pole ExdIICT4 | ||||
Dimensions mmXmmXmm | L2800×W1850×H2250※ | weight t | 3.3 ※ | ||
interface size mm | Inlet DN50/dischargeDN20 | ||||
Drive mode | Direct connection | ||||
Main component materials | frame and slide | cast iron | |||
Piston rings, packing | Filled with PTFE | ||||
Air valve and cylinder liner | Stainless steel | ||||
Scope of supply | Main engine, motor, cooler, oil pump, skid mounted chassis, starter cabinet, intake filter, primary instrument and control components, safety valve, special tools, inlet and outlet matching flanges, random documents, etc. | ||||
Additional notes | 1. On site electrical explosion-proof level ExdIICT4; 2. Lubricating oil to be provided by the user (use low-temperature lubricating oil when the ambient temperature is below 5 ℃). 3. The column data is for user reference, and there may be discrepancies when the machine leaves the factory. | ||||
Delivery time | 80 days after the contract is signed and the advance payment is received | ||||
The above parameters are quoted as standard for our company. If there are special requirements, we will discuss them separately.
The nitrogen compressor has the physical and chemical properties of easy processing, wear resistance, impact resistance and corrosion resistance, which can realize that the running parts accurately meet the production requirements, the service life is better than the traditional repair process, and the anti-corrosion performance is better than the traditional method. And the high-reliability material properties can also prolong the service life of the equipment and make maintenance more worry-free. For the leakage of nitrogen compressor oil, at the same time, the current nitrogen compressor is equipped with a professional engineer team, which can respond quickly 24 hours a day, quickly formulate the repair process, and the process of plugging the leakage is also very simple and convenient, which can greatly shorten the nitrogen compressor for enterprises. Oil spill treatment time, reduce business losses.
