| cooling way: | |
|---|---|
| Color: | |
| packing box: | |
| standard: | |
| ETD time: | |
| Quantity: | |
HW-24/6
BAILIAN
8414804090
refinery oil free hydrogen compressor: filling hydrogen into high pressure bottle for storage, our hydrogen compressor filling pressure 150-200BARG
Decomposition of ammonia to produce hydrogen, pressurized for use in heat treatment of steel mill stainless steel
Photovoltaic power generation + hydrogen refueling station: electricity is produced by photovoltaic power generation, and then hydrogen is produced by water electrolysis. The hydrogen booster compressor supplier in the general hydrogen refining station is pressurized to 400-450 barg, and is filled into a high-pressure hydrogen bottle to supply hydrogen energy vehicles. use.
hydrogen compressor oil free membrane in refinery in chemical reactions, such as hydrogen compressors for polysilicon
S/N | ITEMS | TECHNICAL PARAMETER | |
1 | Working medium | Dry Hydrogen mixed gas ,no H2s, H2 - 35-40% CO + CO2 - 18-20 % | |
2 | Model | HW-24/6 | |
3 | Structure | Totally oil free W type | |
4 | Pressure stage | 2 ,3cylinder | |
5 | Standard delivery Nm3/h | 24(@atmosphere pressure) | |
6 | Rated inlet pressure MPa | atmosphere pressure | |
7 | Rated outlet pressure MPa(G) | 0.6 | |
8 | Inlet temperature℃ | ≤40 | |
9 | Outlet temperature℃ | ≤130 | |
10 | Transmit temperature℃ | ≤45 | |
11 | Speed r/min | 400 ※ | |
12 | Cooling way | Water cooling | |
13 | Lubricate way | Crank shaft,connect rod | Seal grease |
Cylinder | Oil free lubricate | ||
Shaft power | ≤4.3kw | ||
14 | Motor power Kw | 5.5KW 220V 60Hz dⅡCT4 | |
15 | Transmit way | Belt driven | |
16 | Installation way | Has simple basement | |
17 | Automatic control | Exhaust pressure gauge automatic shutdown | |
18 | Dimension L×W×H mm | 1500X1000X1200 ※ | |
19 | Gas inlet mm | 40 | |
20 | Gas outlet mm | 15 | |
21 | Water inlet mm | 15 | |
22 | Water consumption Kg/h | 600 | |
23 | Live electrical explosion-proof rating | dⅡCT4 | |
24 | Weight Kg | 720 ※ | |
25 | |||
26 | Delivery time | 45 days since get payment | |
27 | Quality Standard | China standard | |
28 | Material for parts | ||
cylinder | Stainless steel | ||
Gas valve | Stainless steel | ||
Pipe and cooler | Stainless steel | ||
refinery oil free hydrogen compressor: filling hydrogen into high pressure bottle for storage, our hydrogen compressor filling pressure 150-200BARG
Decomposition of ammonia to produce hydrogen, pressurized for use in heat treatment of steel mill stainless steel
Photovoltaic power generation + hydrogen refueling station: electricity is produced by photovoltaic power generation, and then hydrogen is produced by water electrolysis. The hydrogen booster compressor supplier in the general hydrogen refining station is pressurized to 400-450 barg, and is filled into a high-pressure hydrogen bottle to supply hydrogen energy vehicles. use.
hydrogen compressor oil free membrane in refinery in chemical reactions, such as hydrogen compressors for polysilicon
