Silent Type 3NM3 150bar High Pressure Oil Free Oxygen Compressor

The compressor is suitable for inlet pressure of 3-4 barg (40-60 psig) and exhaust pressure of 150 barg (2150 psig)
cooling way:
standard:
packing box:
start way:
Availability:
Quantity:
  • GOW-3-4-150



S/N

ITEMS

PARAMETER

1

WORKING MEDIUM

OXYGEN O2

2

MODEL

GOW-3/4-150

3

STRUCTURE

100% OIL FREE   RECIPROCATING COMPRESSOR

4

PRESSURE STAGE

2


Cylinder

2

5

OXYGEN CAPACITY(STANDARD   CONDITION)Nm3/h

3

6

RATE INPUT MPa(G)

0.3-0.4

7

RATED OUTPUT MPa(G)

15.0

8

INLET TEMPERATURE

40

9

DISCHARGE   TEMPERATURE

50

10

TRANSMIT   TEMPERATURE

50

11

PUMP SPEED r/min

400

12

COOLING WAY

AIR COOLING

13

LUBRICATE WAY

CRANK SHAFTCONNECT ROD

SEAL GREASE

CYLINDER

OIL FREE   LUBRICATE

14

MOTOR POWER Kw

3

15

TRANSMIT WAY

BELT DRIVEN

16

INSTALLATION WAY

HAS BASEMENT

17

Automatic   control items

Pressure over   loading

18

Dimension  L×W×H mm

700×650×650

19

Inlet and outlet   mm

15

20

Weight Kg

150KGS

21

GW

190KGS

22

Motor

380V 50HZ 3PHASE

23

Working model

6-8hours per day
