VW-20/5-25
BAILIAN
8414804090
screw well-insulated compressor for nitrogen generator
For Laser cutting
Nitrogen acts as a shielding gas in laser cutting. Medium-pressure nitrogen is mainly used to blow away oxygen, preventing metal cutting and surrounding oxidation at high temperatures during cutting, improving the cleanliness of the cutting surface and aesthetics.
this screw nitrogen compressor for nitrogen generator has long time working ,and reliable quality performance ,and long life service time characters
well-insulated screw nitrogen compressor
No | Description | Technical Parameters | |
1 | Working medium | Oil free nitrogen gas | |
2 | Equipment model | VW-20/5-25 | |
3 | Structural style | Oil free v type | |
4 | Compression stage | 2 ,2 cylinder | |
5 | Rated flow(standard state)Nm3/h | 20（suction 5barg） | |
6 | Rated inlet pressure MPa(G) | 0.5 | |
7 | Rated outlet pressure MPa(G) | 2.5 | |
8 | Gas inlet temperature℃ | ≤35 | |
9 | Discharge temperature℃ | ≤130 | |
10 | Gas supply temperature℃ | ≤55 | |
11 | Rotational speed of compressor/min | 550 ※ | |
12 | Type of cooling | air-cooling | |
13 | Method of lubrication | Bent axle、Connecting rod | Sealing grease lubrication |
Air cylinder | Oil free lubrication | ||
Shaft power | ≤2.9kw | ||
14 | Power of motor :Kw | 4kw 380V 50Hz3Ph ※ | |
15 | Transmission way | belt transmission | |
16 | The type of installation | Has simple basement | |
17 | The automatic control | It will be stop by automatic, when the exhaust pressure over | |
18 | The dimension: Long×wide×high mm | 1100×750×950 ※ | |
19 | The size of gas inlet (mm) | DN25 | |
20 | The size of gas outlet(mm) | DN15 | |
21 | In and out of the water interface mm | null | |
22 | Water consumption kg/h | null | |
23 | Weight(Kg) | 300 ※ | |
24 | Delivery date | 25days upon receive the advanced payment | |
25 | Power supply | 380V 50hz 3phase | |
Cylinder | Carbon steel | ||
Valve | Stainless steel | ||
