OW-0.6-20
No | Description | Technical Parameters | |
1 | Working medium | Oxygen gas | |
2 | Equipment model | OW-0.6/20 | |
3 | Structural style | Oil free vertical type | |
4 | Compression stage | 2 | |
5 | Rated flow(standard state)Nm3/h | 0.6 | |
6 | Rated inlet pressure MPa(G) | Atmosphere pressure | |
7 | Rated outlet pressure MPa(G) | 2.0 | |
8 | Air inlet temperature℃ | ≤40 | |
9 | Discharge temperature℃ | ≤130 | |
10 | Air supply temperature℃ | ≤50 | |
11 | Rotational speed of compressor/min | 400 ※ | |
12 | Type of cooling | air-cooling | |
13 | Method of lubrication | Bent axle、Connecting rod | Sealing grease lubrication |
Air cylinder | Oil free lubrication | ||
Shaft power | ≤ 0.23kw | ||
14 | Power of motor :Kw | 1.1KW 415V 50HZ ※ | |
15 | Transmission way | belt transmission | |
16 | The type of installation | Has simple basement | |
17 | The automatic control | It will be stop by automatic, when the exhaust pressure over | |
18 | The dimension: Long×wide×high mm | 700X650X600 ※ | |
19 | The size of gas inlet (mm) | 15 | |
20 | The size of gas outlet(mm) | 15 | |
21 | In and out of the water interface mm | null | |
22 | Water consumption kg/h | null | |
23 | Weight(Kg) | 220 ※ | |
24 | Delivery date | 35 days upon receive the advanced payment |
No | Description | Technical Parameters | |
1 | Working medium | Oxygen gas | |
2 | Equipment model | OW-0.6/20 | |
3 | Structural style | Oil free vertical type | |
4 | Compression stage | 2 | |
5 | Rated flow(standard state)Nm3/h | 0.6 | |
6 | Rated inlet pressure MPa(G) | Atmosphere pressure | |
7 | Rated outlet pressure MPa(G) | 2.0 | |
8 | Air inlet temperature℃ | ≤40 | |
9 | Discharge temperature℃ | ≤130 | |
10 | Air supply temperature℃ | ≤50 | |
11 | Rotational speed of compressor/min | 400 ※ | |
12 | Type of cooling | air-cooling | |
13 | Method of lubrication | Bent axle、Connecting rod | Sealing grease lubrication |
Air cylinder | Oil free lubrication | ||
Shaft power | ≤ 0.23kw | ||
14 | Power of motor :Kw | 1.1KW 415V 50HZ ※ | |
15 | Transmission way | belt transmission | |
16 | The type of installation | Has simple basement | |
17 | The automatic control | It will be stop by automatic, when the exhaust pressure over | |
18 | The dimension: Long×wide×high mm | 700X650X600 ※ | |
19 | The size of gas inlet (mm) | 15 | |
20 | The size of gas outlet(mm) | 15 | |
21 | In and out of the water interface mm | null | |
22 | Water consumption kg/h | null | |
23 | Weight(Kg) | 220 ※ | |
24 | Delivery date | 35 days upon receive the advanced payment |
